SPECIFICATIONS VIDLED Standard LED Series LIGHTS
Here's some detailed information on our lights.  We'll also throw in some halogen lights in the mix, as a comparison to the VIDLED lights.  We've listed the Bescor MLP-645 dimmable halogen light, which uses a 50 W halogen bulb; and a Sunpak Readylight 20 with a 15W bulb.
Please also note the beam angle: a wider beam always yields lower luminocity because the light is spread over a larger area.

Vidled
Vidled
Vidled
Vidled
Sunpak
Bescor
Bescor

WarmLED-40
DayLED-40
CoolLED-40
CoolLED-40
Readylite 20
MPL-645
MPL-645
With 1/2 CTO
gel
  With dichroic
filter
Without
dichroic filter
Power used 3.8 W 3.8 W 5.8 W 5.8 W 15 W 50 W 50 W
Relative Brightness
Color Temperature ~3200 K ~5600 K ~8000 K ~5400 K ~3200 K ~4700 K ~3200 K
Beam angle 40° 40° 40° 40° 25° 30° 30°
Ambient temperature 22°C 22°C 22°C 22°C 22°C 22°C 22°C
Housing temperature 43°C 44°C 46°C 46°C n/a * 67°C 67°C
Luminocity at 1.8m/6ft 39 Lux 62 Lux 124 Lux 80 Lux 68 Lux 102 (60) Lux
**
320 (220) Lux
**

Notes:
*
We didn't measure temperature of housing as the light does not stay on long enough. It's a great little light for the money, but don't expect more than about 15 minutes run time on one charge, and it takes several hours to re-charge the battery pack..
**
Another nice light, but our test-unit had a horrible HOTSPOT in the middle of the beam. Since we measure the center, the above luminocity for the MPL-645 is misleading. Once we even out the beam, we measured: ~60 Lux with dichroic filter, and ~220 Lux without filter.

Which VIDLED is right for you?
VIDLED Comparison

VIDLED
STANDARD
VIDLED
DELUXE
Click small image to view 360° panorama (QuickTime required)
Cost $275.00 USD $435.00 USD
Color Temperature, power consumption:

Brightness:

warmLED in 40° beam, 4W

warmLED in 40° beam, 4W

Color Temperature, power consumption:

Brightness:
dayLED in 40° beam, 4W
dayLED in 40° beam, 4W
Color Temperature, power consumption:

Brightness:
coolLED in 40° beam, 6W
coolLED in 40° beam, 4W
Dimensions 5.5x2x1.6" (142x50x41mm) 5.5x2x1.6" (142x50x41mm)
Weight ~8.6oz, ~245g ~11.5oz, ~335g
Flash shoe mount included YES YES
Internal Battery Pack NO YES
Dimmable YES YES
Running time depends on battery pack

~1.5 hrs
(at FULL power)

Includes a battery meter NO YES (analog readout with LCD)
Functions
Once a power source is plugged in, use the potentiometer to control the amount of light.
No external power source required. A switch turns the battery meter LCD on; once the switch is ON, use the potentiometer to regulate the amount of light.
Usable 1/4" 20 threads 5 (2 on top, 3 on bottom) 1 (1 on bottom)
TWO units can be attached to each other using an attachment kit YES NO
Advantages

+ fully dimmable
+ low cost

+ includes battery pack, and comes with charger (110-240V; 50/60Hz)
+ ready to go
+ VERY convenient
+ no wires/cables coming from the light
+ includes an LCD battery meter
+ fully dimmable
Disadvantages over other lights
- no display of remaining battery power
- requires external power source

- once battery runs out, the unit has to be recharged
- higher initial cost (but no battery pack necessary)
- run time is fixed by the internal battery pack

Comments

Battery pack is Li-Ion, NON replaceable and rated for ~500 recharges. The LEDs should outlive the battery pack. Should the battery pack wear out, the unit is still operational by using an external power source


VIDLED
STANDARD
VIDLED
DELUXE
All units are NON-servicable; please contact VIDLED with technical questions, troubleshooting, and/or warranty issues.
