INDOORS OUTDOORS



Indoors Sample Movie Clips

VIDLED LED lights:	1 x warmLED attached to 1 x coolLED
Date:	June 17, 2005
Camera:	Panasonic DVX100AE (PAL version); attached is a Century Optics wide angle lens adapter.
Location:	darkened room of a house being renovated
Technical details:	Camera was set-up using 16:9 wide screen, L gain, white balanced to daylight, with auto-iris on. NLE is VEGAS 5. There was no post-processing done whatsoever. Fade to and from black is done solely using the VIDLED LED light's dimming feature. QuickTime MOV files are rendered directly from the NLE 'upconverting' to 1024x576 pixels, using SORENSON3 and 5 fps (to reduce file size).

1) VIDLED warmLED only: Fade in and out using warmLED dimmer.
This is white balanced to daylight, hence the yellowish hue.
Remember this only using 4W!
(click image below to view MOV file)



2) VIDLED warmLED only: Fade in using warmLED dimmer --> white balance in DVX camera -->
notice how it nicely removes the yellowish hue --> fade out.
(click image below to view MOV file)



3) VIDLED coolLED only: Fade in and out using coolLED dimmer.
This is white balanced to daylight, hence the blueish hue.
Remember this only using 6W!
(click image below to view MOV file)



4) VIDLED warmLED and coolLED together: Fade in using warmLED dimmer --> add / fade in of coolLED -->
notice how it nicely it goes to daylight --> fade out of warmLED --> fade out of coolLED.
(click image below to view MOV file)





Outdoors Sample

Real life test using two VIDLED LED lights (1 x coolLED-40 and 1 x dayLED-10) click image for larger view, and additional angle

Date of shoot: September 8, 2005, 5:20 p.m. Location: Outdoors, forest, Pennsylvania Conditions: relatively bright, but some cover from trees Subject: female talent in an interview situation Equipment: DVX-100AE, in progressive and 16:9 mode; 1 x coolLED-40 with 1/4 CTO on-camera powered by two 9V batteries; 1 x dayLED-10 attached to a nearby tree with a ULTRAPOD powered by the SLS-DPS lithium ion battery pack.

click image for larger view, and additional angle



Note: unfortunately ZoneAlarm's Ad Blocking feature will prevent this animated GIF file from displaying anything other than the first frame. For the full effect, you will need to set ZA to "AD BLOCKING DISABLED". Animated GIF file showing the effects of the VIDLED lights. Images show: - no lights - coolLED - coolLED & dayLED at 50% - coolLED & dayLED at 100%
